Custom Components
Carbon FiberComposite Parts
Precision post-processing for carbon fiber composite parts — 5-axis CNC trimming, tight-tolerance edge finishing, and drilling for cycling, motorsports, and drone components. From prototype to low-volume production.
±0.02mmTrimming Tolerance
5-XCNC Trimming
1-500Units per Run
5-Axis CNC Trimming
±0.02mm edge accuracy
Complex Geometry Cutting
Drilling & edge finishing
Vacuum Fixturing
Zero part distortion
Carbon Fiber Post-Processing
Precision trimming, drilling, and finishing for cured carbon fiber components — from bike frames to drone parts.5-Axis CNC Trimming
Precision cutting of cured carbon fiber parts to final shape.
Benefits
±0.02mm edge accuracy
No delamination
Smooth cut edges
Fast turnaround
Precision Drilling & Countersinking
High-accuracy hole making for carbon fiber assemblies.
Benefits
Drill-to-CAD accuracy
Countersink depth control
No fiber fraying
Clean holes
Edge Finishing & Surface Prep
Surface preparation for bonding and final assembly.
Benefits
Burr-free edges
Surface prep for adhesive bonding
Consistent finish
Quality inspected
Vacuum Fixturing
Secure holding for complex carbon fiber shapes during machining.
Benefits
No part distortion
Quick setup
Complex shapes
Repeatable results
Technical Specifications
Precision tolerances and capabilities for carbon fiber post-processing — from prototype to low-volume production.
Trimming Tolerance±0.02mm
Max Part Size1500mm x 1000mm x 500mm
Min Wall Thickness0.5mm
Drilling DiameterM2 – M12
Surface FinishRa 1.6µm
Production Volume1 – 500 units
Finishing & QC
CNC Trimming5-axis machining for precise edges
Edge SandingSmooth edges for bonding prep
Surface InspectionVisual check for defects
Non-Destructive TestingUltrasonic inspection for voids
Destructive TestingMechanical testing per ASTM standards
Weight Verification±1% weight tolerance control
Material Performance Comparison
Carbon fiber vs. traditional materials (indexed to aluminum = 1.0)
Material
Specific Strength
Specific Stiffness
Weight
Cost
Carbon Fiber (UD)
4.2
5.8
0.58
8-12
Carbon Fiber (Woven)
3.8
4.2
0.62
6-10
Aluminum 6061-T6
1.0
1.0
1.0
1.0
Titanium Ti-6Al-4V
2.1
1.5
1.65
15-20
Steel 4130
1.3
1.1
2.9
0.8
